SM39TCD split-type temperature sensor features a stainless-steel probe and an aluminum flameproof junction box, widely used for temperature measurement in thermal engineering, power, food, pharmaceutical, pressure vessel, petrochemical, and other process industries, as well as in large equipment such as ovens, plastic and fiber machines, and refrigeration units.
تحميل
مقدمة
SM39TCD split-type temperature sensor features a stainless-steel probe and an aluminum flameproof junction box, widely used for temperature measurement in thermal engineering, power, food, pharmaceutical, pressure vessel, petrochemical, and other process industries, as well as in large equipment such as ovens, plastic and fiber machines, and refrigeration units.
صفات:
- Imported Pt100 element for fast temperature response;
- Sensor shape customizable;
- Temperature range 0–200 °C (tailored);
- Requires pipe drilling and welding, pre-install 1/4″ threaded thermowell or boss;
- Terminal block inside junction box for quick wiring;
- Txplosion-proof design fully compliant with GB 3836.1-2000, GB 3836.2-2000 and GB 3836.4-2000.
الأبعاد
مخطط الدائرة:
Two-wire output: power supply polarity-free
مواصفة
| يكتب | المعايير الفنية |
| نطاق الحمل الاسمي | -30～50℃ |
| الناتج إشارة | 4～20mA |
| دقة الصف | 0.5%FS |
| الرصيد الصفري | ≤0.1%FS |
| مزود الطاقة | 24VDC |
| تعويض درجة الحرارة | -10~65 درجة مئوية |
| درجة حرارة التشغيل | -40 درجة مئوية ≤ تامب ≤ +65 درجة مئوية |
| مادة المادة | يقذف الألومنيوم |
| نوع الحماية | IP66 (IEC60529) |
| علامة مقاومة للانفجار | Ex d IIC T4 Gb |
| رقم مقاوم للانفجار | CE13.1220 |
| طول الكابل | 7.5m |
