Sensor terbuat dari baja paduan atau baja tahan karat dan memiliki struktur kotak diafragma profil rendah. It is produced by introducing raw materials from the United States and the proprietary processing technology of the American BEAN Company. Laser sealing welding, compression bearing.
It is mainly applied to industrial testing systems such as testing machines, truck scales, hopper scales, and warehouse scales, as well as various measuring equipment.
Sensor terbuat dari baja paduan atau baja tahan karat dan memiliki struktur kotak diafragma profil rendah. It is produced by introducing raw materials from the United States and the proprietary processing technology of the American BEAN Company. Laser sealing welding, compression bearing.
It is mainly applied to industrial testing systems such as testing machines, truck scales, hopper scales, and warehouse scales, as well as various measuring equipment.
strong anti-eccentric load capacity, good impact resistance, high precision, corrosion resistance, compact size and easy installation.
Diagram Sirkuit：
Merah: ＋masukan
Biru：-masukan
Putih： + keluaran
Kuning： -keluaran
| Jenis | Parameter teknis |
| Kisaran beban nominal | 1～150t |
| Catu daya | Tegangan 10~12 Volt |
| Saldo nol | 1.0±% dari keluaran terukur |
| Keluaran analog | 2,0±0,015mV/V |
| Resistansi masukan (Rlc) | 775±5Ω（ohms） |
| Resistansi keluaran (Ro) | 700±2Ω（ohm） |
| Resistansi isolasi | ≥5000 MΩ (Mega-Ohm) |
| Presisi kelas | 0,05%FS |
| Pengaruh suhu | 0,05%FS/10℃ |
| Suhu operasi | -40～+85℃ |
| Batas Beban Aman | 200% FS |
| Margin keamanan terhadap imbal hasil | 300% FS |
| Margin keamanan terhadap kerusakan | 500% FS |
| Bahan bahan | Baja paduan kinerja tinggi atau (rasio kromium>15% baja tahan karat) |
| Jenis perlindungan | Tingkat IP66 |
